Specifications: Gas tanker trailer for sale, 40 feet 3 axles – AMT-GAS-403-J3
Type: Fuel Tanker Trailer
Dimensions (+/-)
- Length x Width x Height: 11,050 x 2,500 x 4,000 mm
- Base Dimensions: 6,715 + 1,310 + 1,310 mm
Weight (+/-)
- Unladen Weight: 7,180 kg
- Load Capacity: 31,820 kg
- Total Weight: 39,000 kg
Structure (+/-)
- Main Beam: I 200 x 140 x 14 x 14 x 6 mm, composite steel beam SM490YA or ASTM A572
Components
- Landing Gear: Jost brand, 28-75 tons
- Kingpin: 2”
- Suspension: 2 leaf springs 100 x 38 mm
- Axles: Germany brand, 3 x 13.8 tons
- Wheels: 8.25×22.5
- Tires: 11R22.5
- Brakes: Double diaphragm T30/30, air brake valve, air hoses, air tanks
- Painting: Shot blasting, anti-corrosion epoxy primer, two-component PU topcoat
- Electrical: 24 Volt, 7-wire. Front, rear, side lights. Phillips-USA air connectors and sockets
- Mudguards: Plastic
Fuel Tank (+/-)
- Capacity: 43,000 liters
- Dimensions: 10,910/10,630 x 2,450 x 1,880 mm
- Specialized Equipment: Fuel loading and unloading valve system
- Material: Aluminum alloy 5083P
Seemore: Gas tanker trailer for sale
“Difficult trailer engineering, trust Asean.”
When it comes to challenging trailer engineering, trust Asean. Our expertise in crafting reliable and robust trailers ensures that even the most demanding transportation needs are met with precision and durability. Asean’s commitment to quality and innovation means you can depend on us for exceptional performance and safety in every trailer we build. For difficult trailer engineering, Asean is the name you can trust.
