Specifications: Gas tank trailer 40 feet 3 axles – AMT-GAS-403-K5
Type: Gas tank trailer
Model: AMT GAS-403-K5
Dimensions (+/-)
- Length x Width x Height: 11,695 x 2,500 x 3,760 mm
- Wheelbase: 6,920 + 1,310 + 1,310 mm
Weight (+/-)
- Unladen Weight: 7.250 kg
- Load Capacity: 31.830 kg
- Total Weight: 39.080 kg
Structure (+/-)
- Main Beam: I 200 x 140 x 14 x 14 x 6 (mm)
- Landing Gear: Jost brand, 28 – 75 tons, China
- Kingpin: 2”, China
- Suspension: 2 leaf springs 100 x 38 mm, China
- Axles: BPW brand, 3 x 12 tons, China
- Wheels: 12 units, China
- Tires: 11R22.5, 12R22.5
- Brakes: ABS, Double diaphragm T30/30 SAP-USA, air brake valve Sealco, air hoses, air tanks
- Painting: Shot blasting, anti-corrosion epoxy primer, two-component PU topcoat
- Electrical: 24 Volt, 7-wire. Front, rear, side lights. Phillips-USA air connectors and sockets
- Mudguards: Plastic
Fuel Tank (+/-)
- Capacity: 43,000 liters
- Dimensions: 11,180/10,920 x 2,500 x 1,840 mm
- Specialized Equipment: Fuel loading and unloading valve system
- Material: Aluminum alloy 5083P
“Difficult trailer engineering, trust Asean.”
When it comes to challenging trailer engineering, trust Asean. Our expertise in crafting reliable and robust trailers ensures that even the most demanding transportation needs are met with precision and durability. Asean’s commitment to quality and innovation means you can depend on us for exceptional performance and safety in every trailer we build. For difficult trailer engineering, Asean is the name you can trust.
