Name: 50' Gooseneck Trailer - ASEAN G503-P3 | High-Quality 3-Axle
Availability: InStock

50′ gooseneck trailer, 3 axles ASEAN G503-P3

The ASEAN G503-P3 is a robust 50′ gooseneck trailer designed for heavy-duty transport. Measuring 15,600 x 2,500 x 1,500 mm with a tare weight of 5,700 kg, it boasts a load capacity of 33,000 kg. Built with a composite I-beam (ASTM A572 steel), it includes features like 28-80 ton landing gear, 13-ton suspension, and Germany-brand axles. The trailer is equipped with dual-chamber brakes, 24V lighting, and Phillips-USA connectors. Finished with anti-corrosion epoxy primer and a durable PU topcoat, this 50′ gooseneck trailer ensures long-lasting performance.

Specifications: 50′ gooseneck trailer, 3 Axles

Model: ASEAN G503-P3

Dimensions (+/-)

Length x Width x Height: 15,600 x 2,500 x 1,500 mm
Base Dimensions: 8,750 + 1,310 + 1,310 mm

Weight (+/-)

Tare Weight: 5,700 kg
Load Capacity: 33,000 kg
Total Weight: 38,700 kg

Structure (+/-)

Main Beam: Composite I-beam 420 x 140 x 14 x 14 x 6 mm, ASTM A572 or equivalent steel
Landing Gear: 28 – 80 tons, China
Kingpin: 2”, China
Suspension: 13 tons, 8 leaf springs 90 x 16 mm, China
Axles: Germany brand, 3 x 13.8 tons, China
Wheels: 8.25×22.5, 9.00V-22.5
Tires: 11R22.5, 12R22.5
Brakes: Dual-chamber, air brake valves, air hoses, air tanks
Painting: Shot blasting, anti-corrosion epoxy primer, two-component PU topcoat
Electrical: 24 Volt, 7-wire. Front, rear, side lights. Phillips-USA air connectors and sockets
Mudguards: Steel; plastic
Twist Locks: 6 positions (48′ + 45′ containers)

50' gooseneck trailer — 50′ gooseneck trailer drawing

“Difficult trailer engineering, trust Asean.”

When it comes to challenging trailer engineering, trust Asean. Our expertise in crafting reliable and robust trailers ensures that even the most demanding transportation needs are met with precision and durability. Asean’s commitment to quality and innovation means you can depend on us for exceptional performance and safety in every trailer we build. For difficult trailer engineering, Asean is the name you can trust.
